DURAREEL
HOSE REELS
Spring-driven automatic retraction keeps hoses off wet floors, reduces tripping hazards, and extends hose life. Available in powder coated steel (DR8) and electropolished 316 stainless steel (DR8S).
DURAREEL DR8
STANDARDThe DR8 is SuperKlean's workhorse hose reel — heavy-duty steel construction with a durable powder coat finish that resists corrosion and wear. Ideal for most food, beverage, and industrial washdown applications where stainless steel is not required.
DR8 HIGHLIGHTS
- Powder coat finish resists corrosion and wear
- Lower cost vs. stainless — ideal where SS not required
- 304 SS non-corrosive spring motor
- Same heavy-duty chassis as DR8S
SPECIFICATIONS
| Parameter | Value |
|---|---|
| Part Number | DR8 |
| Body Material | Heavy duty steel — powder coat finish |
| Spring Material | 304 Stainless Steel |
| Finish / Color | Charcoal / Black powder coat |
| Inlet / Outlet | 1/2" NPT |
| Max Water Pressure | 300 PSI |
| Max Water Temperature | 200°F (93°C) |
| Max Hose Capacity | 50 ft of 3/4" ID hose |
| Axle Diameter | 1" — dual axle support |
| Weight | 69 lbs |
| Inlet Swivel Connection | 90° 1/2" NPT (brass or SS) |
| Spring Motor | Enclosed cartridge-style, factory-tuned |
| Guide Arm Positions | Wall, floor, vehicle, overhead |
ORDERING INFORMATION
| Part # | Description | Finish |
|---|---|---|
| DR8 | Powder coated heavy duty steel spring driven hose reel | Powder Coated Steel |
| DR8S | Electro-polished heavy duty stainless steel spring driven hose reel | Electropolished Stainless Steel |
Also available:
REQUEST INFORMATION
Fill out the form below and a SuperKlean specialist will contact you.
- Antimicrobial Microban HoseMBW / MBY — pairs perfectly with DuraReel
- Standard Washdown HosesUW / UB / UR — EPDM, 300 PSI
- Hose Racks (Wall Mount)Models 11, 11-S, 12, 12-S, 12-SS
- DuraLife Swivel AdaptersO-ring swivel, 2.25" barbs
- 8000 Series Steam MixersDuraMix steam & cold water stations
- 3600 Series Hot & Cold MixersHot & cold water mixing stations
BUILT FOR INDUSTRIAL WASHDOWN
Dual Axle Support
1" axle with dual axle support system provides increased stability, reduced vibration, and structural integrity under heavy daily use.
Auto-Retract Spring Motor
Enclosed, factory-tuned cartridge-style spring motor with non-corrosive stainless steel spring, pawl, and multi-position lock ratchet mechanism.
Adjustable Guide Arm
Solid one-piece heavy gauge 1/4" base and support post. Guide arm adjusts to wall, floor, vehicle, and overhead positions for maximum installation flexibility.
Hot Water Rated
Rated to 200°F (93°C) and 300 PSI — handles the full temperature and pressure range of SuperKlean hot water washdown systems.
KEEP HOSES OFF THE FLOOR
Modern plant managers and safety crews pay close attention to keeping large, hot water hoses off the ground. Wet hoses slow floor drying and create tripping hazards. Hot water hoses dragged across concrete floors accumulate microscopic grooves that shorten their lifespan.
SuperKlean DuraReel hose reels have been used in the finest food and beverage production facilities worldwide for over 30 years — providing automatic retraction that minimizes the work required of plant personnel and keeps floors safer and drier between washdown cycles.
- Keeps hoses off wet floors — reduces tripping hazards for plant workers
- Drier floors between washdown cycles — inhibits bacterial and pathogen growth
- Extends hose life by eliminating floor abrasion and microscopic groove formation
- Faster, more efficient washdown — workers retrieve and store hoses in seconds
- Compact wall-mount footprint — ideal for plants with limited floor space
- Reduces hose kinking, tangling, and premature wear
APPLICATIONS
DIMENSIONS & MOUNTING OPTIONS
DR8 / DR8S DIMENSIONS
| Dimension | Inches | Metric |
|---|---|---|
| Disc Diameter | Ø 24.00" | [610 mm] |
| Overall Width | 25.50" | [648 mm] |
| Guide Arm Offset A | 6.00" | [152 mm] |
| Guide Arm Offset B | 5.00" | [127 mm] |
| Pedestal Height | 4.00" | [102 mm] |
| Axle Diameter | 2.09" | [53 mm] |
| Drum Depth | 5.50" | [140 mm] |
| Inlet Height | 6.00" | [152 mm] |
| Wall Clearance | 0.72" | [18 mm] |
| Mounting Hole Spread | 9.88" | [249 mm] |
MOUNTING OPTIONS
Standard configuration. Mounts to wall studs or structural steel. Guide arm adjusts for optimal hose routing.
Pedestal base bolts to floor or overhead structure. Ideal where wall mounting is not practical.
Undercarriage mount for mobile washdown carts and vehicles. Keeps reel protected and hose accessible.
Guide arm adjusts to wall, floor, vehicle, and overhead positions. Specify mounting option when ordering if non-standard configuration is required.
INSTALLATION GUIDE
From the official DR8 & DR8S Installation and Maintenance Manual. Save and display prominently where this equipment is used.
INLET HOSE INSTALLATION
- 1
Apply thread sealant to inlet hose and connect to the swivel joint on reel.
Use a FLEXIBLE inlet hose. Do not use solid piping or restrain inlet hose — side force on the swivel joint voids the warranty. - 2
Flush product through the system before connecting inlet hose to the supply source.
- 3
Install inlet hose into swivel assembly by hand tightening, then ½ turn with wrench. Do not over-tighten — may damage swivel.
- 4
If reel includes hose: flush product through system before connecting end fitting, nozzle, or tool.
- 5
If reel is supplied less hose: apply thread sealant to outlet hose fitting. Connect end fitting, nozzle, or tool as desired.
- 6
If hose stopper adjustment is required: latch reel at desired location, loosen the two ball stop bolts, move ball stop, tighten bolts, then unlatch reel.
- 7
Connect inlet hose to supply source.
OUTLET HOSE INSTALLATION
- 1
Securely stabilize the reel.
Note: Ensure you are installing the correct size, length, and type of hose per the reel rating. Consult factory if unsure. - 2
Wind the reel drum clockwise (facing the swivel) until the spring is tight.
Use extreme caution when winding the drum. - 3
Back off approximately two turns and lock the reel drum to prevent rotation.
- 4
Insert the MALE fitted end of the hose through the roller guide arm and through the cutout in the side of the drum flange.
- 5
The MALE hose fitting should now be on the outside of the drum. Apply thread sealant, connect hose fitting to the swivel joint, and secure the hose with the two hose clamps.
Note: Hose clamps restrain the hose when fully extended, preventing strain between fittings and swivel joint. - 6
CAREFULLY release the locking ratchet and SLOWLY allow the hose to retract onto the reel.
MAINTENANCE PROCEDURES
Step-by-step procedures for spring tension adjustment, swivel seal replacement, and spring canister replacement.
- 1Release line pressure prior to making spring adjustments.
- 2Disconnect inlet hose.
- 3Pull out approximately 6 feet (2 m) of hose and latch the drum.
- 4Add or subtract one wrap of hose to acquire proper tension. Adding wraps increases tension; subtracting decreases tension.
- 5Unlatch drum and check for proper tension.
- 6Reconnect inlet hose.
TROUBLESHOOTING GUIDE
Common issues and remedies from the official DR8 & DR8S Installation and Maintenance Manual.
If you cannot resolve the issue using this guide, contact Northeast Controls / SuperKlean technical support directly.
